TYPE |
Color Laser Multifunctional |
CORE FUNCTIONS |
Standard: Print, Copy, Scan, Send, Store
Optional: Fax |
PROCESSOR |
1.8 GHz Dual Core Processor |
CONTROL PANEL |
10.1″ TFT LCD WSVGA Color Touch-panel |
MEMORY |
3.5 GB RAM |
SOLID STATE DRIVE |
Standard: 256 GB/Maximum: 1 TB |
INTERFACE CONNECTION |
Network: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)
Optional: NFC, Bluetooth Low Energy
Others
Standard: USB 2.0 x1 (Host), USB 3.0 x1 (Host), USB 2.0 x1 (Device)
Optional: Copy Control Interface |
PAPER CAPACITY (LETTER, 20 LB. BOND) |
Standard: 1,200 Sheets
Maximum: 2,300 Sheets |
PAPER SOURCES (LETTER, 20 LB. BOND) |
Standard: Dual 550-sheet Paper Cassettes, 100-sheet Multipurpose Tray
Optional: Dual 550-sheet Paper Cassettes (Cassette Feeding Unit-AW1) |
PAPER OUTPUT CAPACITY (LETTER, 20 LB. BOND) |
Standard: 250 Sheets
Maximum: 3.450 Sheets (with Staple Finisher-AE1/Booklet Finisher-AE1 and Copy Tray-T1) |
FINISHING CAPABILITIES |
Standard: Collate, Group
With Finishers: Collate, Group, Offset, Staple, Saddle-Stitch, Hole Punch, Eco Staple, Staple On Demand |
SUPPORTED MEDIA TYPES |
Multi-purpose Tray: Thin, PLain, Heavy, Recycled, Coated, Color, Tracing, Bond, Transparency, Label, Pre-punched, Envelope, Letterhead
Upper Cassette: Thin, Plain, Heavy, Recycled, Color, Tracing, Bond, Transparency, Pre-punched, Envelope, Letterhead
Lower Cassette: Thin, PLain, Heavy, Recycled, Color, Bond, Transparency, Pre-punched, Envelope1, Letterhead |
SUPPORTED MEDIA SIZES |
Multi-purpose Tray: 12″x18″, 11″x17″, Legal, Letter, Letter-R, Executive, Statement, Statement-R Custom Size/Free Size: 4″ x 5-7/8″ to 12″ x 18″, Envelopes (COM10 No.10, Monarch, ISO-C5, DL), Envelope Custom Size ( 3-7/8″ x 3-7/8″ to 12-5/8″ x 18″)
Upper Cassette: Letter, Executive, Statement-R Custom Size (4-1/8″ x 5-7/8″ to 11-3/4″ x 8-1/2″), Envelopes (ISO-C5)
Lower Cassette: 12″ x 18″, 11″ x 17″, Legal, Letter, Letter-R, Executive, Statement-R, Custom Size (4-1/8″ x 5-7/8″ to 12″ x 18″), Envelopes (COM10 No.10, Monarch, DL) |
SUPPORTED MEDIA WEIGHTS |
Cassettes: 14 lb. Bond to 140 lb. Index (52 to 256 g/m2 )
Multipurpose Tray: 14 lb. Bond to 110 lb. Cover (52 to 300 g/m2 )
Duplexing: 14 lb. Bond to 80 lb. Cover (52 to 220 g/m2 ) |
PRINT/COPY SPEED (BW AND COLOR) |
Up to 26 ppm (Letter); Up to 20 ppm (Letter-R); Up to 15 ppm (Legal/11″ x 17″) |
WARM-UP TIME |
From Power On: Approx. 10 Seconds2
From Sleep Mode: Approx. 10 Seconds3
Quick Startup Mode: Approx. 4 Seconds4 |
DIMENSIONS (W x D x H) |
22-1/4″ x 28-1/2″ x 35-3/8″ (565 mm x 722 mm x 897 mm)5 |
INSTALLATION SPACE (W x D x H) |
Basic: 38-1/2″ x 44-1/8″ (978 mm x 1119 mm)6
Fully Configured: 65″ x 44-1/8″ (1651 mm x 1119 mm)7 |
WEIGHT |
Approx. 185.2 lb. (84 kg)8 |
PRINT RESOLUTION (dpi) |
1200 x 600, 1200 x 1200 |
STANDARD PAGE DESCRIPTION LANGUAGES |
UFR II, PCL6, Adobe PS3 |
SUPPORTED FILES |
PDF, TIFF, JPEG, EPS, XPS |
PRINTING FROM MOBILE AND CLOUD-BASED SERVICES |
A range of standard and optional software and MEAP-based solutions (including AirPrint, Mopria, Universal Print by Microsoft® , Canon PRINT Business, and uniFLOW Online) are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements. Please contact your sales representative for further information. |
FONTS |
PCL: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T (Japanese, Korean, Simplified and Traditional Chinese),9 Barcode Fonts10
PS: 136 Roman |
OPERATING SYSTEM 11 |
UFRII/PS: Window® 8.1/10/Server2012/Server 2012 R2/Server 2016/Server 2019, Mac OS X (10.11 or later)
PCL: Window® 8.1/10/Server 2012/Server 2012 R2/Server 2016/Server 2019
PPD: Window® 8.1/10, Mac OS X (10.11 or later) |
FIRST-COPY-OUT-TIME |
Approx. 6.1 seconds (BW)/ 8.4 seconds (Color) |
COPY RESOLUTION (dpi) |
600 x 600 |
MULTIPLE COPIES |
Up to 999 |
MAGNIFICATION |
25%-400% (1% Increments) |
PRESET REDUCTION / ENLARGEMENT |
25%, 50%, 64%, 73%, 78%, 100% (1:1), 121%, 129%, 200%, 400% |
TYPE |
Single-pass Duplexing Automatic Document Feeder12 |
DOCUMENT FEEDER PAPER CAPACITY |
Up to 200 sheets (20lb. Bond) |
DOCUMENT FEEDER SUPPORTED MEDIA SIZES |
11″ x 17″, Legal, Letter, Letter-R, Statement, Statement-R, Custom Size: 2-3/4″ x 5-1/2″to 12″ x 17″ (69.9 mm x 139.7 mm to 304.8 mm x 431.8 mm) |
DOCUMENT FEEDER SUPPORTED MEDIA WEIGHTS |
BW/Color Original: 13.3 lb. Bond to 80 lb. Cover (50 to 220 g/m2 ) |
PLATEN ACCEPTABLE ORIGINALS |
Sheet, Book, 3-Dimensional Objects |
PLATEN MAXIMUM SCANNING SIZE |
Up to 11-3/4″ x 17″ (297.0 mm x 431.8 mm) |
PULL SCAN |
Color Network ScanGear2 for both Twain and WIA Supported OS: Window® 8.1/10/Server 2012/Server 2012 R2/Server 2016 |
SCAN RESOLUTION (dpi) |
Scan for Copy: 600 x 600
Scan for Send: Push (600 x 600), SMB/FTP/WebDAV, Pull (600 x 600)
Scan for Fax: 600 x 600 |
SCAN TO MOBILE DEVICES AND CLOUD-BASED SERVICES |
A range of solutions is available to provide scanning to mobile devices and cloud-based services depending on your requirements. |
SCAN SPEED (LETTER) |
Single-sided Scanning: 135 ipm (300 dpi)/80 ipm (600 dpi)
Double-sided Scanning: 270 ipm (300 dpi)/160/90 ipm (600 dpi) |
DESTINATION |
Standard: E-mail/Internet FAX (SMTP), SMB 3.0, FTP, WebDAV, Mail Box
Optional: Super G3 FAX, IP Fax |
ADDRESS BOOK |
LDAP (2,000)/Local (1,600)/Speed Dial (200) |
SEND RESOLUTION |
Push: Up to 600 x 600 dpi
Pull: Up to 600 x 600 dpi |
COMMUICATION PROTOCOL |
File: FTP (TCP/IP), SMB 3.0 (TCP/IP), WebDAV
Email: SMTP, POP3 |
FILE FORMAT |
TIFF, JPEG, PDF(Compact, Searchable, Apply Policy, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word) |
MAXIMUM NUMBER OF CONNECTION LINES |
2 |
MODEM SPEED |
Super G3: 33.6 Kbps
G3: 14.4 Kbps |
COMPRESSION METHOD |
MH, MR, MMR, JBIG |
RESOLUTION |
400 x 400, 200 x 400, 200 x 200, 200 x 100 |
SENDING / RECORDING SIZE |
Statement-R to 11″ x 17″ |
FAX MEMORY |
Up to 30,000 Pages (2,000 Jobs) |
SPEED DIALS |
Max. 200 |
GROUP DIALS / DESTINATIONS |
Max. 199 Dials |
SEQUENTIAL BROADCAST |
Max. 256 Addresses |
MEMORY BACKUP |
Yes |
MAIL BOX SIMPLE (NUMBER SUPPORTED) |
100 User In-boxes, 1 Memory RX In-box, 50 Confidential Fax In-boxes, Maximum 10,000 Pages (2,000 Jobs Stored) |
ADVANCED BOX |
Communication Protocol: SMB or WebDAV
Supported Client PC: Windows (Windows 8.1/10)
Concurrent Connections (Max.)
SMB: 64
WebDAV: 3 (Active Sessions) |
ADVANCED BOX AVAILABLE DISC SPACE |
Standard: 16 GB (With Option: max. 480 GB) |
AUTHENTICATION AND ACCESS CONTROL |
User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online Express13 (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control) |
DOCUMENT SECURITY |
Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print14), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle® Rights Management ES2.5 Integration), BOX Security (Mail Box Password Protected, Advanced Space Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/ Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark) |
NETWORK SECURITY |
TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/ Wired LAN), Disabling Unused Functions (Enabling/Disabling Protocols/Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), Communication Line Separation (G3 FAX, USB Port, Advanced Space, Scan and Send-Virus Concerns for E-mail Reception) |
DEVICE SECURITY |
Protecting SSD Data [SSD Data Encryption (FIPS140-2 Validated), SSD Lock], Standard SSD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Protecting MFP Software Integrity, Checking MFD Software Integrity (Verify System at Startup, Runtime Intrusion Detection) |
DEVICE MANAGEMENT AND AUDITING |
Administrator Password, Digital Certificate and Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting |
OPERATING ENVIRONMENT |
Temperature: 50 to 86 ºF
Humidity: 20 to 80 % RH (Relative Humidity) |
POWER REQUIREMENTS |
110V-127V, 60Hz, 8.5A |
POWER CONSUMPTION |
Maximum: Approx. 1,500 W
Standby: Approx. 43.9 W15
Sleep Mode: Approx. 0.8 W16
Typical Electricity Consumption (TEC) Rating 0.30 kWh17 |
STANDARDS |
ENERGY STAR® Certified
Rated EPEAT® Gold |
TONER CARTRIDGE18 |
GPR-53 Toner BK/C/M/Y
GPR-53L Toner C/M/Y
|
TONER YIELD (ESTIMATED @ 5% COVERAGE) |
GPR-53 Toner BK: 36,000 pages
GPR-53 Toner C/M/Y: 19,000 pages
GPR-53L Toner C/M/Y: 8,500 pages
|
